Fravol Edgebander F600
The FRAVOL EDGEBANDER F600 series is designed for the craftsman seeking evolved and efficient solutions. These edge banders deliver exceptional working quality with minimal intrusion, ensuring that precision and performance are never compromised. At an accessible price point, they provide a perfect balance of advanced technology and affordability. The series incorporates a blend of innovative solutions, versatile applications, and cutting-edge technologies, all wrapped in a sleek and modern design. Whether you’re aiming for superior craftsmanship or streamlined production, the FRAVOL EDGEBANDER M-400-23 series promises to meet your needs with style and efficiency.
- Crafted with precision
Product Features
Robust and Rigid Structure
- Ribbed Electrically Welded Steel Frame: Designed to ensure high rigidity and durability.
- Compact and Versatile Design: User friendly and adaptable to various machining tasks.
- Crafted with precision
Product Features
Enhanced Functionality
- Extensible Panel Support: Facilitates machining of large panels.
- Integrated Electrical Cabinet: Equipped with a main switch for ease of use and safety.
- Crafted with precision
Product Features
Precision and Safety
- Digital Position Indicator: Accurate reading slip through the digital position indicator.
- Protective Cabin: Wide-opening cabin offers an excellent view of inner parts, complete with a safety switch.
- Innovation. Automation. Satisfaction.
Design Features
With all Farnese machines, we pride ourselves on making features simple to use. Our commitment to intuitive design ensures ease of operation and minimal training requirements.
High performance machining centre incorporating italian technology.
Emergency mushroom buttons placed at the entrance and exit of the machine.
Dust extraction has individual outlets positioned on top of the cabin. Number and location of the outlets according to the machine configuration.
All motors turn at 12,000 RPM and are controlled by an inverter of suitable power according to machine configuration.
The machine management is ensured by an operator panel with a 7″ colour touchscreen fitted in a handy position.
Automatic loading of the roll edging material up to 3 mm thick with motorized positioning device; complete with revolving coil holder dia 800 mm.
Technical Specifications
| Technical Specifications | Metric |
|---|---|
|
Length |
10 – 45 mm. (10-60mm optional 15) |
|
Depth |
7,0 mt/min ( 9,0 mt/min optional 100 ) |
|
Height |
15 – 65 mm |
|
Weight
|
0,4 – 3,0 mm |
|
Panel Thickness
|
1,00 Kg |
|
Minimum Panel Width |
230/400 V 50/60 Hz. – 3 Ph+N |
|
Minimum Panel Length |
140 mm. (PVC) |
|
Edge Width |
80 mm |
|
Edge Thickness |
6 bar |
|
Dimensions of machine |
1000 Kg |
|
Pneumatic Power |
3700 mm |
|
Power Supply
|
Min. 15 °C / Max. 45 °C (Min. 59 °F / Max: 113 °F) |
|
|
400V-415V 3P N 50Hz |
